Part Number: V MAX SHO 90hp

Part Number: V MAX SHO 90hp

HIGH POWER ( 200- 90HP)

V MAX SHO 90hp

A lightweight heavyweight


In technical terms, the V MAX SHO is a masterpiece of engineering craftsmanship. In order to achieve the results we wanted – low weight with high performance - our engineers came up with a single overhead camshaft format, with 4 large valves per cylinder and a special long-track intake manifold.

At a glance


  • Incredible acceleration – perfect for lightweight boats
  • Class-leading torque and high-speed performance
  • Compact design – more power delivered for less weight
  • Distinctive & well-known ‘V MAX SHO’ cowling design
  • High output 35A alternator – power from low RPM
  • Smooth and quiet - for relaxed boating and fishing
  • Unmatched Yamaha reliability


Engine


  • Engine type 4-stroke
  • Displacement 1.832cc
  • No. of cylinders/Con guration 4/in-line, 16-valve, SOHC
  • Bore x stroke 81,0 x 88,9 mm
  • Prop shaft output at mid range 66.2 kW / 90 HP
  • Full Throttle Operating Range 5000 - 6000 r/min
  • Lubrication system Wet sump
  • Fuel Induction System EFI
  • Ignition / advance system TCI
  • Starter system Electric with Prime Start™
  • Gear ratio 2.33 (28/12)


Dimensions


  • Transom height L: 516mm / X: 643 mm
  • Oil pan capacity 3.2L / 3.0L
  • Weight without propeller 162kg - 166kg
